Case Studies

Scan Hub has scanned and modeled hundreds of factories used for steel fabrication, food processing, materials handling, and many other uses, either full of machines or empty, for many clients Australia-wide. Process Facility 3D laser scanning and scan-to-BIM The Challenge Large factories full of machine lines and complexity require experience to capture in 3D. Scan Hub has over 10 years of this experience, and we're armed with the best laser scanning technology. Placement and

We have more than 10 years of experience and knowledge in 3D laser scanning many rail track maintenance machines and other rolling stock for many clients Australia-wide. Rail Track Maintenance Machine - Laser Scanning for Certification The Challenge Rolling stock machines are complex and big. Capturing these machines in 3D with sufficient detail and accuracy for scan-to-BIM deliverables requires knowledge and experience. Our Solution Scan Hub has solutions and experience to s

Scan Hub has undertaken many 3D laser scanning and CAD Modelling projects for clients installing and maintaining pumps and impellers used in water treatment, mining sludge transfer, and industrial sites Australia-wide. Volute Pump Housing - Laser Scanned and CAD Modeled The Challenge The organic shapes of volute-style pump housings and associated impellers are complex to measure with any method other than 3D laser scanning. The curves and mating surfaces required for these pu

Scan Hub was engaged by a fuel system management client to support the redesign of components in the fuel storage site at an Australian domestic airport. The project formed part of an overall system review of aircraft refueling at this Capital City airport. The Challenge The fuel storage facility is a highly dangerous environment for any work activity. Scan Hub operators had the experience to adhere to strict safety protocols and procedures to enter the site and conduct exten
